1964.5-1966 Ford Mustang 289 Aluminum Performance Radiator. MT Cars. These COLD-CASE radiators are Tig welded 100 percent aluminum and absolutely beautiful.
Don't buy a 3 or 4 row aluminum radiator! It doesn't cool as good as these oversize 2 row models. Original fan shroud will mount with original mounting brackets.
These radiators are original appearing and have the correct stamping. Once painted, you'd be hard pressed to find a difference over an original versus a COLD-CASE.
- 100 percent TIG welded
- All Aluminum
- Polished OE style tanks
- 16 fins per inch
- Corrugated fins that give more surface area and more thermal transfer
- Pressure tested
- For manual trans
- Direct fitment for 64.5-66 Mustang w/ 289 V8
- Old Part Number: RPE564
Radiator Specs
- Core Height 16.5 inch
- Core Width 16.85 inch
- Overall Height 21 inch
- Overall Width 19.6 inch
- Overall Thickness 3 inch
- Tubes (2) 1.25 inch Tubes
